3D CAD files

(STEP) file downloads for Alvium

Here you can download STEP files for Alvium cameras.

About Alvium STEP files

This page provides STEP file components for the numerous Alvium hardware options.

Please read the Assembly Instructions document to learn:

Which components you need to download.
How to assemble your Alvium submodel from these STEP file components.

Downloading STEP files for standard Alvium cameras

You need a 3D CAD viewer application to view and measure the STEP files. Download a STEP viewer free of charge: https://www.freecad.org.
To assemble housed cameras from the STEP file components, follow the Assembly Instructions document included in the link collection.

Alvium housings

// C-Mount and CS-Mount front housings with small filter window

These front housings are used for the following color and monochrome models (by sensor):

030 VSWIR (IMX991), 040 (IMX287), 050 (P480), 120 (AR0135), 130 VSWIR (IMX990), 158 (IMX273), 210 (AR0521), 240 (IMX392), 500 (AR0521), 501 NIR (AR0522)

// C-Mount and CS-Mount front housings with large filter window

These front housings are used for the following color and monochrome models (by sensor):

052 VSWIR (IMX426), 203 (IMX422), 234 (IMX249), 235 (IMX174), 291 (IMX421), 319 (IMX265), 320 VSWIR (IMX993), 507 (IMX264), 508 (IMX250), 510 (IMX248), 511 (IMX547), 530 VSWIR (IMX992), 811 (IMX546), 812 UV (487), 895 (IMX267), 1236 (IMX304), 1240 (IMX226), 1242 (IMX545), 1620 (IMX542), 2040 (IMX541), 2050 (IMX183), 2460 (IMX540)

// S-Mount front housings without filter window

Alvium S Mount Body

This front housing is used for all color and monochrome models.

// Back housings

Bare Board Cameras

// Standard Alvium CSI-2 bare board cameras

The following STEP file downloads apply to Alvium CSI-2 cameras, but also to assemble housed Alvium G1, G5, FP3, and GM2 cameras.

Note: The STEP file downloads for Alvium bare board cameras have been updated to the new hardware design according to the PCN Alvium CSI-2 + USB Mainboard Version Update. If you need STEP data for the previous hardware design, please contact our Technical Support team.

// Standard Alvium USB bare board cameras

Note: The STEP file downloads for Alvium bare board cameras have been updated to the new hardware design according to the PCN Alvium CSI-2 + USB Mainboard Version Update. If you need STEP data for the previous hardware design, please contact our Technical Support team.

// Alvium Flex bare board cameras

STEP files are common for CSI-2 and USB.

More downloads

// Alvium Flex accessories

Downloads include the available components by interface.

// Alvium Frame

To be combined with the corresponding bare board camera.

Alvium Frame

// Alvium G1 BL (Board Level)

To be combined with the corresponding Alvium Flex bare board model (and front housing for G1 BL cameras with mount).

Alvium G1 BL 60mm Kit
